DMC 635 V | Bewema

Vertical Machining Center DMC 635 V
Back

Stable vertical Machining Center with full-fledged 4th Axis, Production Paket, Extended Paket, as well as Blum Laser Tool Measuring in Top Condition.

New Spindle 2013.

Üretici: DMG

Model: DMC 635 V

Üretim yılı: 2006

Motor gücü: 19 kW

Devreye alınma tarihi: 08/2006

Eksen sayısı: 4

Kontrol ünitesi: Siemens 840 D / Shop Mill

Fener milli çalışma saati: 6.000 h

Takim tutucu tipi: SK 40

Devir kapasitesi: 20 bis 12.000 U/min

Takim magazini: 30 -fach

X Eksen hareketi: 635 mm

Y Eksen hareketi: 510 mm

Z Eksen hareketi: 460 mm

İlerleme hızı: 20.000 mm/min

Boşta ilerleme: 30 m/min

Tabla ebadı: 790 x 560 mm

Kurulum ölçüleri BxTxH: siehe Plan cm

Ağırlık: 3.700 kg

Extendet Paket, composed of reinforced Spindle with higher rotational-Speed range, bigger Tool-changer, Cooling for Main drive, direct Way-measuring system in all axis and sealing air for Way-measuring systems
Production Paket, containing of IKZ 20 bar, Paperband filter, Chip conveyor, Rotoclear, Cleaning pistol, Air Blast shiftable
NC-Dividing Head Lehmann EA 410 with Spindle Clamping and additional hand-held control
Areal transformation for NC-Dividing Head
Tool Laser Measuring Probe Blum
Control Mode 4

The Machine can be seen and tested in our Stock after agreement.

Errors and omissions excepted.
